Support Beams

Faroex's pultruded fibreglass-reinforced beams are configured to provide the design flexibility you need when laying out your barn. Backed by our 10-year Conditional Warranty, you can depend on Faroex beams for the ultimate in stiffness, strength, and corrosion resistance. Select from the following beams to tailor your design to your exact requirements. Refer to the Accessories page for leg sets, caps, brackets, and other components for a complete system.

Box I-Beam

• Maximum 9’ (274 cm) span with pigs up to 100 lbs. (45kg)
• Maximum 7’ (213 cm) span for Farrowing
• Application: Main support frame for Farrowing and Nursery Floors

H.D.Box I-Beam

• Maximum 10’ (305cm) span with pigs up to 100 lbs. (45kg)
• Maximum 8’ (244cm) span for Farrowing
• Application: Main support frame for Farrowing and Nursery Floors



H.D.I-Beam

• Maximum 36” (91cm) span with pigs up to 100 lbs. (45kg)
• Maximum 24” (61cm) span for Farrowing
• Application: Assembly support frame for Farrowing and Nursery Floors



Super I-Beam

• Maximum 50” (128cm) span with pigs up to 100 lbs. (45kg)
• Maximum 42” (106cm) span for Farrowing
• Application: Assembly support frame for Farrowing and Nursery Floors

Polybeam

• Maximum 8’ (244cm) span with pigs up to 100 lbs. (45kg)
• Maximum 7’ (213cm) span with pigs over 100 lbs. (45kg)
• Application: Main support frame for Farrowing, Nursery and Grower Floors

Maxispan

• Maximum 12’ (366cm) span with pigs up to 100 lbs. (45kg)
• Maximum 10’ (305cm) span with pigs over 100 lbs. (45kg)
• Application: Main support frame for Farrowing, Nursery and Grower Floors
